DJLT02H-17-26PN
DJLT02H-17-26PN Square Flange Mount, Hermetic MS27471 Type, Shell Size 17 with 26#20 Pin Contacts, N Orientation.
RoHS Compliant: Yes
Technical Specifications
| Manufacturer | Detoronics |
|---|---|
| Connector Style | Square Flange Receptacle |
| Contact Gender | Pin – Male |
| Contact Size | 26#20 |
| Contacts Supplied | Yes |
| Coupling Style | Bayonet |
| Insert Keyway | Normal |
| Insert Arrangement | 17-26 |
| Shell Material | Carbon Steel |
| Shell Size | 17 |
Environmental Specifications
| Operating Temperature | 4?C + 90?C – 39?F +201?F |
|---|---|
| RoHS Compliant | Yes |
| Insulation Resistance | 000 megohms AT 500VDC, 5 |
Quality & Compliance
| Qualified | No |
|---|---|
| Specification | MIL-DTL-38999 SI Type |
| Series | DJLT Series |
